USB & MIPI Common Mode Chokes for High-Speed Data Transmission

Ensuring signal integrity while minimizing electromagnetic interference (EMI) has become paramount, especially with the proliferation of USB and MIPI interfaces in modern devices. Addressing this critical need, Abracon introduces its advanced USB & MIPI Common Mode Chokes, meticulously engineered to support next-generation interfaces and deliver superior performance.

Optimized for High-Speed Interfaces

Abracon's USB & MIPI Common Mode Chokes are specifically designed to cater to high-speed data protocols, including, USB 3.2, and MIPI D-PHY/C-PHY. Operating effectively over a broad frequency range of 0.5 to 5GHz, these chokes ensure robust performance and efficient noise suppression, making them indispensable for applications requiring rapid data transfer and minimal latency.

Key Features and Benefits

1. Compact Form Factor: Measuring a mere 0.65mm x 0.50mm x 0.30mm, these chokes are ideal for space-constrained applications, allowing for seamless integration into compact designs without compromising functionality.
2. Effective Noise Suppression: With tailored impedance characteristics, they proficiently suppress common mode noise, thereby preserving signal integrity and enhancing overall system performance.
3. High Impedance at GHz Frequencies: Ensures high-frequency noise is effectively attenuated, which is crucial for maintaining the quality of high-speed data transmissions.
4. Low DC Resistance (DCR): The minimized DCR contributes to energy efficiency, making these components suitable for power-sensitive applications where conserving energy is essential.

Diverse Applications

The versatility of Abracon's USB & MIPI Common Mode Chokes makes them suitable for a wide array of applications, including:

• Portable Electronics: Smartphones, tablets, and ultra-thin laptops benefit from enhanced data transmission quality and reduced EMI, leading to improved user experiences.
• Wearable Devices: Compact size and efficient noise suppression are critical products such as AR/VR headset, Smartwatches, etc, ensuring reliable performance in a small form factor for applications where PCB area is a premium
• Automotive Electronics: In automotive infotainment and navigation systems, maintaining signal integrity amidst various electronic components is crucial for safety and functionality.
• IoT Devices: For connected devices where reliable data transmission and energy efficiency are paramount, both of which are supported by these chokes.

By effectively suppressing EMI without compromising signal integrity, these components empower engineers to develop innovative, high-performance products that meet the rigorous demands of today's technology landscape.

For more detailed information and to explore the full range of Abracon's USB & MIPI Common Mode Chokes, visit the official product page.
